1-4m Stationary Electric Hydraulic Scissor Lift Table for Sale

Basic Specifications

Model NO.

HW

Lift Mechanism

Scissor Lift

Driven Type

Hydraulic

Feature

Explosion-Proof

Certification

GS, CE, RoHS, ISO 9001

Voltage

110V, 220V, 380V, 400V, Customized

Load Capacity

1000kg, 2000kg, 4000kg, Customized

Lifting Height

1m, 1.3m, 1.4m, 1.5m, Customized

Origin

China

Capacity

1000 Set/Month

Portable Hydraulic Scissor Lift Table

This hydraulic table is our standard model, equipped with a single layer scissor mechanism. With a maximum platform height of 3000mm and load capacities of 1000kg and 2000kg, it is designed for versatility and reliability.

Safety is paramount; hence the table is equipped with safety valves to protect both goods and users. Optional customizations include rollers, organ covers, and wheels to meet specific operational requirements.

Technical Parameters

Model	Load Capacity (KG)	Self Height (MM)	Max Platform Height (MM)	Platform Size (MM)	Lifting Time (S)	Net Weight (KG)
HW1001	1000	205	1000	1300×820	20~25	160
HW1002	1000	205	1000	1600×1000	20~25	186
HW1003	1000	240	1300	1700×850	30~35	200
HW2001	2000	230	1000	1300×850	20~25	235
HW2004	2000	250	1300	1700×1000	25~35	300
HW4001	4000	240	1050	1700×1200	30~40	375
HW4006	4000	300	1400	2200×1200	35~40	505
HW501L	500	200	1000	1200*600	20~25	120

Features & Advantages

✓

Surface Treatment: Shot blasting and stoving varnish with superior anti-corrosion function.

✓

Stability: High-quality pump station ensures stable lifting and falling.

✓

Durability: Anti-pinch scissor design with self-lubricating pin-rolls to prolong life span.

✓

Safety Sensors: Aluminum safety sensor under the platform prevents pinching during descent.

✓

Standards: Fully compliant with American ANSI/ASME and European EN1570 standards.

✓

Adjustable Speed: Flow control valve allows for customizable descent speeds.

Product Display

Safety Precautions

⚠

Explosion-proof valves: Protects the hydraulic pipe from rupture.

⚠

Spillover valve: Prevents high pressure and allows for pressure adjustment.

⚠

Emergency decline valve: Allows the platform to lower manually during power outages.

⚠

Overload Protection: Specialized locking device to prevent dangerous overload operations.

Frequently Asked Questions

Q1: What is the maximum load capacity available?

We offer standard models with 1000kg, 2000kg, and 4000kg capacities. Customized solutions for other weight requirements are also available.

Q2: Can the voltage be customized for different countries?

Yes, we support various voltage configurations including 110V, 220V, 380V, and 400V to suit your local power standards.

Q3: What safety features are built into the scissor lift?

The lift includes explosion-proof valves, an emergency decline valve, aluminum safety sensors to prevent pinching, and overload protection devices.

Q4: Is the lift table suitable for outdoor or harsh environments?

Yes, the surface is treated with shot blasting and stoving varnish, providing excellent anti-corrosion properties suitable for various industrial environments.

Q5: What are the options for customization?

Common customizations include adding rollers on top, protective curtains, wheels for mobility, guardrails, or battery-operated moving systems.

Q6: Does the product meet international quality standards?

Absolutely. Our scissor lift tables are CE, GS, RoHS, and ISO 9001 certified, meeting American ANSI/ASME and European EN1570 standards.
